From 60-Pin to 200-Pin: The Versatility of the LFH Connector

Ensuring signal quality in any high-density connector requires a focus on good design principles. The LFH connector itself helps by incorporating a ground plane in many designs, which provides a low-inductance reference for the signals. When you partner with KinKuo to create a cable assembly, we can take this a step further. To maximize signal quality, we can build your breakout cable using individually shielded twisted pairs for your sensitive or high-speed signals. This ensures that each signal is protected from interference from its neighbors (crosstalk) and from external noise (EMI). By combining the well-designed LFH connector with a high-quality, properly shielded cable construction from KinKuo, you can be confident in the integrity of every one of your data channels.

This is a classic high-density breakout scenario, often found in test and communication systems. You have a central unit with a single, high-density LFH connector, and you need to connect it to several peripheral devices that use standard D-SUB connectors. The clean and reliable solution is a custom "fan-out" or "octopus" cable. KinKuo is an expert in building these complex harnesses. We can design and manufacture a cable that starts with a single LFH-160, for example, and breaks out into multiple DB-9, DB-15, or DB-25 connectors, with each branch labeled for easy identification and built to the exact length you need. This custom assembly eliminates a nest of clumsy adapters and provides a robust, single-piece solution for your complex interface requirements. Let KinKuo simplify your connectivity with a custom LFH connector to D-SUB breakout cable.

Finding a manufacturer who can reliably build a complex, fine-pitch breakout cable for an LFH connector can be challenging. This is not a simple assembly, and it requires specialized tooling and a high degree of skill to produce correctly. You need to find a factory with proven experience. KinKuo is a specialist in this exact area. We have been manufacturing custom LFH connector cable assemblies for 15 years. We have the expertise, the equipment, and the rigorous 100% testing procedures to ensure that every single one of the dozens or hundreds of connections in your breakout cable is wired perfectly. Don't risk your project on an inexperienced assembler. For a reliable, zero-defect custom LFH breakout cable, KinKuo is your trusted, expert manufacturing partner.

To provide you with a fast and accurate quote for a custom LFH-200 connector assembly, we need a few key pieces of information. First, we need the pinout: a wiring diagram or "from-to" list that specifies which pin on the LFH-200 connects to which pin on the other end(s) of the cable. Second, we need to know the desired connector(s) for the other end of the cable (e.g., screw terminals, D-SUBs, etc.). Third, tell us the overall length of the cable and the lengths of any individual breakout branches. Finally, let us know any special requirements for the cable itself (e.g., does it need to be shielded, high-flex, or have a specific color?) and your estimated order quantity. With this information, the team at KinKuo can provide you with a comprehensive and competitive quote for your custom LFH connector assembly.
